PSH2405C is a 2-phase CANOpen open-loop driver with 32-bit DSP technology, offering low noise and vibration. It supports position, speed, and multi-segment position control via standard MODBUS-RTU over RS-485. Features include 4 optically isolated inputs, 2 outputs, smooth current control with adjustable drive current up to 1.5 A, DC24–36 V input, and protection against over-voltage, under-voltage, and over-current. Up to 30 drives can be controlled simultaneously.
